Plastic Processing Machinery manufacturer offer tape stretching lines for their use in various applications including hdpe tape plants, pp tape plants, pp raffia tape plant, woven sack plant, pp fibrillated tape plant, pp fibrillated rope plant, pp rope plant, pp fibrillated cable filler plant and in pp stretching yarn/thread from Blown Film Plants in Ahmedabad, India.

HDPE Raffia Tape Plant Manufacturer :: HDPE Raffia Tape Plant Exporter :: HDPE Raffia Tape Plant Supplier


HDPE/PP Raffia Tape Plants for Woven Sack Cloth ...


We are renowned as a world wide leader in manufacturing HDPE Raffia Tape Plants from India. We offer quality range of PP Plants made using the latest technologies available in the industry. Our plant is equipped with micro-processor for operating control and frequency conversion for speed control.

Our company holds proficiency as a preeminent manufacturer of Woven Sack Processing Machinery offered with highest performance and at economical prices.  Our plants have gained great appreciation due to its exceptional features such as durability, rugged construction, high functionality and strength. These plants are very easy to operate and convenient to maintain.

Blown Film Plant is also counted as a real exporters and suppliers of Plastic Extrusion Machinery from Gujarat. Our PP Raffia Plants finds application in Fertilizer and Chemical Industry,  Fabric For Lamination, Tarpauline and other industries.

Models
TWS-65
TWS-75
TWS-90
TWS-100
TWS-125
TWS-150
Extruder Screw Diameter 65 mm 75 mm 90 mm 100 mm 125 mm 150 mm
Extruder Screw L/D Ratio 30:1 30:1 28:1 28:1 28:1 28:1
Extruder Motor KW 15.0 KW 22.4 KW 30.0 KW 37.0 KW 55.0 kW 75.0 KW
Maximum Output Kg/hr 50-60 80-90 90-100 130-140 190-210 250-280
First gadget motor 2.0 KW 3.73 KW 3.73 KW 5.00 kW 7.5 KW 10.0 kW
Second gadget motor 3.73 KW 5.00 kW 5.00 kW 7.5 kW 10.0 kW 15.0 KW
*Orientation chamber heating load 12.0KW 15.0 kW 25.0 kW 27.0 KW 30.0 kW 40.0KW
*Total connected load 50.0 KW 65.0 kW 90.0 kW 115.0 KW 150.0 KW 200.0 KW
Cheese winder winding stations 80 Nos. 80 Nos. 110 Nos. 110 Nos. 140 Nos. 200 Nos.
Cheese winder  connected load 20.0 KW 20.0 KW 27.5 KW 27.5 KW 35.0 KW 50.0 KW
* Orientation chamber is available with gas ignition heating also.
* Above plant with GROOVE FEED screw barrels for high output

Models
TWS-65 TWS-75 TWS-90 TWS-100 TWS-125 TES-150
Extruder Motor KW
22.4 KW 30.0 KW 37.0KW 55.0 kW 75.0 KW 100.0 KW
Maximum Output Kg/hr
80-90 90-100 130-140 190-210 250-280 330-360
